Product Features
Interaction Upgrade
Support multi-screen interaction from teachers and students, comparison, sharing, and collaborative inquiry learning
9-Split Screen Cast
Up to 9 split screens can be displayed at the same time
Real 4K Screen Cast
Screen casting resolution can reach real 4K
Wi-Fi 6
There is zero lag and the screen delay is less than 0.1 seconds
Dual 4K
1x HDMI OUT (4K) + 1x HDMI IN (4K)
Split-screen Layout
Supports 20 split-screen layouts
Multi-device Connection
Simultaneous support for 16 devices
Mirror Control
Support PC, mobile phone, iPad to mirror control at the same time
Customization
Supports user-defined main interface icons to meet the needs of different scenarios
Cloud Cast
Supports meeting cast, remote cast, and casting over countries
Technical Parameters
|
Parameter Type |
Content |
|
|
Power |
Supply |
AC 110-240V/50-60Hz |
|
Rated power |
Standby power: <0.15W Working Rated Probability: 12±0.5W |
|
|
System Parameters |
System |
Android 11.0 |
|
CPU |
RK3568 Quad-Core 64bit Cortex-A55 @1.8GHz |
|
|
GPU |
Mali-G52 2EE |
|
|
Storage Memory |
EMMC 16GB |
|
|
Operating Memory |
DDR 2GB |
|
|
Hard Drive File System |
FAT16/FAT32/NTFS |
|
|
Supported Languages |
Chinese/English/French/German/Spanish/Italian/ etc multilateral languages |
|
|
External Interfaces |
USB |
2 Type-A USB3.0,2 Type-A USB2.0 and 1 Type-C USB2.0 |
|
HDMI IN |
HDMI 2.0：1024×768,1366×768,1280×720,1280×800 1920×1080,1920×1200,3840×2160(30Hz) |
|
|
HDMI OUT*2 |
HDMI 2.0：1024×768,1366×768,1280×720,1208×800,1920×1080,1920×1200,3840×2160(Main Screen： up to 4K/60Hz,Secondary Screen： up to 2K/60Hz) |
|
|
Audio Input |
HDMI IN / 3.5mm TRS jack |
|
|
Audio Output |
HDMI OUT / 3.5mm TRS jack |
|
|
Wired Network |
1000Mbps, RJ45 (standard modular connector) |
|
|
Multimedia Support |
Decoding Formats |
H.265HEVC/MVC Main10 Profile yuv420@L5.1 up to 4096x2304@60fps H.264 AVC/MVC Main10 Profile yuv400/yuv420/yuv422/@L5.1 up to 4096x2304@60fps VP9 Profile0/2 yuv420@L5.1 up to 4096x2304@60fps VP8 verision2,up to 1920x1088@60fps VC1 MPEG-4 MPEG-2 MPEG-1 up to 1920x1088@60fps |
|
Video Formats |
Avi/Ts/Vob/Mkv/Mov/ISO/wmv/asf/flv/dat/mpg/mpeg |
|
|
Audio Formats |
MP3/WMA/AAC/WAV/OGG/DDP/HD/FLAC/APE |
|
|
Image Formats |
HD JPEG/BMP/GIF/PNG/TIFF |
|
|
Basic Functions |
Wireless Hotspot |
WIFI6：5GHz/2.4GHz 802.11 a/b/g/n/ac |
|
Max. Hotspot Speed |
Up to 1201 Mbps |
|
|
Device Capacity |
Supports up to 9 connected devices |
|
|
Wireless Connectivity |
Dual-Band Wi-Fi: 5GHz + 2.4GHz |
|
|
Bluetooth |
Bluetooth V5.0 |
|
|
Scheduled Power On/Off |
Timer Range: 0–24 hours Minimum Interval: 10 minutes between power cycles |
|
|
Electronic Whiteboard |
Supported |
|
|
Annotation |
Supported |
|
|
Environmental Parameters |
Temperature Range |
Operating: 0°C to +50°C Storage: -20°C to +60°C |
|
Humidity |
Operating: 0 to 85% relative humidity, non-condensing Storage: 0 to 90% relative humidity, non-condensing |
|
|
Screen Mirroring Parameters |
Receiver Frame Rate |
25fps or below |
|
Average Transmission Latency |
<150ms@10m/1080P |
|
|
Visible Transmission Distance |
>30m@1080P |
|
|
Software Mirroring Support |
Windows / Android / iOS / |
|
|
Hardware Mirroring Support |
Windows / Mac OS |
|
|
Third-party Protocols |
AirPlay/DLNA/Miracast |
|
|
Proprietary Protocol |
Transcreen |
|
|
Touch Back Control |
10-point @Windows/macOS |
|
|
Split Screen |
1/2/4/5/6/8/9 |
|
|
Screen Layout Modes |
21 types |
|
|
Mirroring Code Generation |
Local device/Server |
|
|
Presenter Privileges |
1 person (transferable) |
|
|
Wireless Annotation |
Supports <128 participants |
|
|
Wireless Speaking |
Mutually exclusive |
|
|
Mirror Control |
Presenter only |
|
|
Main Mirroring Device |
Configurable |
|
|
QR Code Functions |
Download APP/Connect to Wi-Fi |
|
